試驗室篩分、標準篩技術參數 Technical Parameter

振動篩適用于地質、冶金、燃化、建工、水泥、醫院、化工、粉體、國防等科研、院校實驗室化驗，試驗物料篩分分析。

AK、AG型焦炭轉鼓機械篩，適用冶金、鐵礦、燒結、球團礦等試驗篩分，分析。本產品由原地礦部唯一指定企業生產，執行行業標準。

Vibrating Screen is applicable to be used in labs of research institutes and institutions of higher learning in geological, metallurgical, fuel chemical, building engineering, cement, hospital, chemical, powder, national defense and other industries for screening and analysis of test materials.

AK、AG Model Coke Rotary Drum Mechanical Screen is applied to test, screening and analysis of metallurgical and sintered pellets and iron. The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.

ISO-1605鼓前一次振動篩、二次振動篩適于冶金、鐵礦石、燒結礦、球團礦等實驗篩分之用。

ISO-1605 Pre-drum Primary and Secondary Vibrating Screen is applied for screening of refractory gold ,iron, sintered, pellet ores and other materials in labs.

型號規格 Model	篩框尺寸Screen size	篩孔尺寸 Hole size	層數Number	給料粒度 Feed size	處理量capacity	功率power	質量 weight
篩分設備技術參數 Screens
	mm	mm		mm	t/h	kw	kg
3GS500×1000三層振篩機 Three tiers screen	500×1000	6-25	3	＜80	≤10	0.75	400
AK98型焦炭轉鼓機械篩 Machinery screen	1600×500	25-40	2	＜80		3-4	980
AG98型焦炭篩分給合式機械篩 Machinery screen		25-40		＜80		＜4
標準篩 Standard screen	φ200	20-200 （目）		≤0.5
SHXL500細粒連續振篩機 Fine size continue shake sifting machlng	Φ500		2	≥0.064	80	1.1	160
