試驗室CGZM型智能液晶顯示振動磨樣機技術參數

一、用途

I. Purpose

適用將各種硬度的干的或濕的化驗樣料，以快速研磨至分析細度。

This machine is used to grind dry or wet sample materials for chemical examination with various hardness degrees to certain fineness.

電力及采礦：加工煤炭、礦石以便作物理或化學分析,冶金行業研磨高爐爐渣或鑄件樣品作分析用，陶瓷行業研磨燒結部件，耐火材料、瓷器，水泥和建材行業加工粗粉末或加工熟料以檢查礦物結構；各種巖石料欄制備，商檢局檢查進出口物料的成分等。

It is used in power and mining industries to process coal and ores for physical and chemical analysis; in metallurgy industry to grind blast-furnace slag or casting samples for analysis; in ceramic industries to grind and sinter parts, fireproof materials and ceramics; and in cement and building material industries to process coarse powder or process clinker to examine mineral structure. It is also used to fabricate various rock materials and examine the ingredients of the import and export materials by the commodity inspection and testing bureau.

二、特點

II. Characteristic

用沖擊力和磨擦力快速研磨（一般1-3分鐘），噪音低，無粉塵污染，工作清潔方便，研磨時間、速度可設置，研磨密封性好，料樣無損失，設置安裝無需地基處理，電機特殊制造，壽命更長，液晶屏幕顯示研磨時間及速度，人性化設計任意設計時間，自動停機。

Rapid grinding through impact force and frictional force (usually 1 to 3 minutes), low noise, no dust pollution, easy cleaning, grinding time and speed able to be set, no loss of material samples, foundation treatment unnecessary for setup and installation, special manufacturing of motor, longer service life, LCD display of grinding time and speed, humanized design of time, and automatic shutdown,

型號規格Model	單位 Uite	CGZM-100	CGZM-400	CGZM-1000	CGZML-120	2CGZM-100
料缽材質 Materials		錳鋼	錳鋼	錳鋼	錳鋼	錳鋼
料缽個數 No.	個	1	1	1	1	2
裝料量 Capacity	g/ 缽	150	350-450	≤1000	連續進出料	2×150
裝料粒度 Feed size	mm	<12	<25	<12	<15	<12
出料粒度 Output size	目	120-350	120-350	120-350	120-350	120-350
研磨時間 Milling time	min	1-3	2-5	2-5	1-3	2-5
電機功率 Power	kw	1.1	1.1	1.1	1.1	1.1
外形尺寸overall dimensions	mm	643×565 ×745	745×743 ×910	750×750 ×1000	515×660 ×1060	550×553 ×825
整機重量 Weight	kg	185	450	468	350	300

型號規格Model	單位 Uite	3CGZM-100	5CGZM-100	7CGZM-100	CGZM-50	3CGZM-50
料缽材質 Materials		錳鋼	錳鋼	錳鋼	剛玉	剛玉
料缽個數 No.	個	3	5	7	1	3
裝料量 Capacity	g/ 缽	3×150	5×150	7×150	50	3×50
裝料粒度 Feed size	mm	<12	<12	<12	<5	<5
出料粒度 Output size	目	120-350	120-350	120-350	200-400	200-400
研磨時間 Milling time	min	2-5	2-5	3-5	≤30	≤30
電機功率 Power	kw	1.1	1.1	1.1	1.1	1.1
外形尺寸overall dimensions	mm	550×553 ×825	815×720 ×912	815×720 ×912	501×495 ×643	550×553 ×825
整機重量 Weight	kg	300	330	330	90	300
