該泵適用于實驗室輸送礦漿，藥劑和粘稠液體。QBGⅡ型膠管泵采用變頻技術，無級調速，數字顯示，排量可調，調速精確，運轉可靠。
This pump is used in laboratory to transport slurry, reagent, and viscous liquid. QBG II hose pump employs frequency conversion technology. It enjoys advantages including stepless speed regulation, digital display, adjustable discharging amount, accurate speed regulation, and reliable operation.
| 型號規格Model | 單位 Uite | XB19 | QBGⅡ |
| 轉速 Speed | r/min | 120 | 120-180 |
| 流量 Flow rate | mL/min | 12 | 100-1600 |
| 揚程 Lift | m | 15 | 2-4 |
| 膠管直徑 Dia. | mm | Ф9×4 | Ф6、Ф9 |
| 功率 Power | w | 250 | 140 |
| 外形尺寸 Overall dimensions | mm | 400×340×330 | 300×146×130 |
| 質量 Weight | kg | 25 | 10 |
