FXZ浮選柱 Flotation column

工作原理：旋流微泡浮選柱采用射流原理，將旋流器與浮選柱有效結合。通過渣漿泵產生高壓礦漿經氣泡發生器(礦漿預備器）產生微泡，由旋流器后脫粗后<0.5mm礦物流入浮選柱進行選別。機器適用<0.5mm以下的煤泥、赤鐵礦、有色礦、非金屬礦、含油污水處理、廢紙脫墨等細粒度、灰分高、泥質多的物料分選。具有節能高效，富集比大,泡沫產品品位高，工藝流程簡化。節省設備投資25%、省電70%、節能藥劑10%。占地少，結構簡單，無傳動部件，操作方便，易于自動化控制，維修方便等特點。

Working principle: Cyclo-microfroth flotation column effectively  combines cyclone and flotation column based on jet principle. The high-pressure  slurry produced through slurry pump produces microbubbles via bubble generator  (slurry preparer). After the minerals are coarsely grinded by cyclone till the  thickness is <0.5mm,  they flow to the flotation column for sorting. Such machine applies to the  sorting of materials with fine grains, high ash content and much mud such as  coal slime smaller than 0.5mm,  hematite, non-ferrous metals, non-metalliferous minerals, oily sewage and waste  paper. It has characteristics such as energy conservation and high efficiency,  large concentration ratio, high grade of froth products, as well as simple  process flow. Such equipment can save 25% of equipment investment, 70% of  electricity, and 10% of reagent. It occupies small land and is simply  structure, free of transmission parts, easy for operation, automatic control  and maintenance.
