PB型耙斗裝巖機Scraper ramp has
PB系列耙斗裝巖機具有效率高、結構緊湊、應用范圍廣等特點。用于巷道掘進中配合礦車進行裝巖。不僅可以在30°以下上山、下山巷道裝巖，還可以進行掘進工序的平行作業，提高掘進速度，是實現巷道掘進機械化的主要機械設備之一。
Series PB scraper Ramp has the feafureshighefficiency,construction andwidespread applications.they are mainlyused for loading cars in the drift,Theycould be used not only for ramping in thehorizontal drift,but also on the slopebelow 30° and for the patallel combiningwords too,to improve the drifting speed.Itis a main mechanical equipment torealize the mechanization of drifting.
| 型號規格 Model | 單位Uite | P-15B | P-30B | P-60B | P-90B |
| 耙斗容積 Olrme of bucket | m3 | 0.15 | 0.3 | 0.6 | 0.9 |
| 技術生產率 Rate of Ortput | m3 /h | 15-25 | 35-50 | 75-110 | |
| 鐵軌軌距 Gauge of Raols | mm | 600 | 600/762/900 | 600/762/900 | |
| 主繩牽引力 Pulling Force of Working Rope | KN | 7.2-10.4 | 13.5-19.5 | 23.3-32.7 | |
| 主繩牽引速度 Pulling Force of Working Rope | m/s | 0.9-1.4 | 0.85-1.22 | 0.97-1.35 | |
| 容繩直徑 Rope Diamerer | mm | 9.3 | 12.5-14 | 15.5 | |
| 容繩量 Rope | m | 56 | 85-75 | 80-70 | |
| 功率 Power | kw | 11 | 17 | 30 | |
| 電動機工作電壓 Motor Votage | V | 380/660 | 380/660 | 380/660 | |
| 外形尺寸 Overall Dim. | mm | 5480×1550 ×1800 | 6600×2045 ×1950 | 9800×2750 ×2220 | |
| 總重量Total weight | kg | 2196 | 3692 | 5415 |
